GPR COBRA PLUG-IN
Airborne ground-penetrating radar
Orion 160S plus an SE-150 antenna: a 2,400-metre survey line per flight, without touching the ground.
- 2,400 m
- profile per flight
- 20–280 MHz
- frequency band
- 3.5 kg
- antenna weight
- 110 min
- endurance without payload
Ground-penetrating radar sees beneath the surface. Putting it on a flying platform transforms the survey: swamp, deep snow and inaccessible terrain no longer stop a vehicle, and the complex flies the profile at constant speed.
The complex is built around the COBRA Plug-in SE-150 antenna: a 20–280 MHz band, 124 MHz centre frequency and 3.5 kg of weight. At 2 m/s, one flight yields a survey line of up to 2,400 metres.
Applications
- Engineering and geological surveys
- Locating buried utilities
- Road pavement and bridge inspection
- Archaeological prospecting
- Ice and soil thickness measurement
Technical specifications
| Parameter | Value |
|---|---|
| Antenna model | SUBECHO SE-150 |
| Frequency range | 20–280 MHz |
| Bandwidth | 260 MHz |
| Centre frequency | 124 MHz |
| Dimensions (L × W × H) | 92 × 22 × 22 cm |
| Antenna weight | 3.5 kg |
| Carrier platform | ORION 160S |
| Complex take-off weight | 20.11 kg (with 4×6S 16,000 mAh batteries) |
| Estimated endurance without payload | 110 min |
| Maximum survey line | 2,400 m (at 2 m/s) |
Gallery
GPR COBRA PLUG-IN
